Double Head Chamfering Machine

Double Head Chamfering Machine


HS-DEF-52FA Double Head Pipe Chamfering Machine

       Inquire Now

Tags :

-- Semi-automatic with manual feeding,automatic chamfering driven by hydraulic.
-- Chamfering in one side(flat face),two sides(internal and external of tube) or three sides(flat face,internal,external) can be chosen as your requirement.
-- Material Available: Carbon Steel,Stainless Steel,Copper,Aluminum...
-- Chamfering knife forward,backword and chamfering working all automatically driven by hydraulic.
-- Chamfering process can be finished at one time in fast speed and accurate chamfering requirement.
-- Clamp device and knife holder are precisely designed for ensure the center line between workpiece and knife holder at the same level.
-- Good mechanical parts ensure machine runs in high stability.
Name DEF-52FA
Main Motor Power 1.5 KW
Chamfering Capacity Pipe :¢12—¢52mm
Solid Bar:¢5—¢30mm
Standard Knife Plate One Set
Chamfering Speed one time 3 S
Main Spindle Rotating Speed 1100 RPM
Hydraulic Motor Power 1.5KW
Air Pressure 6kg
Control Method Hydraulic
Machine Size 1600*1000*1100
Machine Weight 780KGS




Factory Direct

Direct Shippment, Direct Price, Direct QC 6000 square meters factory, Over 150 employees work in shift ensure the punctual delivery time.

Good Quality

Received CE, ISO9001, CQC, TUV Certificate. Inspection is carried out all through the production process, warranty card provided.

OEM Service

R&D team is qualified to do customized project, OEM services. Away from Shanghai the biggest sea port of China, only 150KM away.

16Y Export Experience

Export to over 108 countries/region. Our HUASHUN machines are spread all over the world.


Sample tube that can be processed
